Rheological properties
| Property | Test Condition | Unit | Standard | typical Value | |
| C | Melt volume-flow rate | 240 °C/ 5 kg | cm³/10 min | ISO 1133 | 40 |
| Melt viscosity | 1000 s-1/ 260 °C | Pa·s | b.o. ISO 11443-A | 105 | |
| Molding shrinkage, parallel | 150x105x3 mm³/ 240 °C / MT 80 °C | % | b.o. ISO 2577 | 0.5 - 0.7 | |
| Molding shrinkage, normal | 150x105x3 mm³/ 240 °C / MT 80 °C | % | b.o. ISO 2577 | 0.5 - 0.7 | |
Mechanical properties (23 °C/50 % r. h.)
| Property | Test Condition | Unit | Standard | typical Value | |
| C | Tensile modulus | 1 mm/min | MPa | ISO 527-1,-2 | 2700 |
| C | Yield stress | 50 mm/min | MPa | ISO 527-1,-2 | 60 |
| C | Yield strain | 50 mm/min | % | ISO 527-1,-2 | 3.5 |
| Stress at break | 50 mm/min | MPa | ISO 527-1,-2 | 45 | |
| Strain at break | 50 mm/min | % | b.o. ISO 527-1,-2 | > 40 | |
| Izod impact strength | 23 °C | kJ/m² | ISO 180/U | N | |
| Izod notched impact strength | 23 °C | kJ/m² | ISO 180/A | 13 | |
| Izod notched impact strength | -30 °C | kJ/m² | ISO 180/A | 8.0 | |
